ACA6/15/60/150/300A刻度值的±3%ACV150/300/600V刻度值的±3%DCV60V刻度值的±3%Ω1/10kΩ(中间值25/250Ω)刻度的±2%TemperatureNote:TheMODEL2608Aincludesatemperaturemeasurementscale

AC A6/15/60/150/300A 刻度值的±3%
AC V150/300/600V 刻度值的±3%
DC V60V 刻度值的±3%
Ω1/10kΩ (中间值 25/250Ω )
刻度的±2%
TemperatureNote: The MODEL2608A includes a temperature measurement scale,
but it is not available for new customers due to the discontinue of the Temperature Probe 7060.
Conductor sizeØ33mm max.
Frequency response50Hz/60Hz
Applicable standardsIEC 61010-1 CAT III 300V Pollution Degree 2
IEC 61010-2-031
IEC 61010-2-032
Power sourceR6 (AA) (1.5V) × 1
Dimensions193(L) × 78(W) × 39(D)mm
Weight275g approx.
Included Accessories7066A (Test leads)
8923 (Fuse [0.5A/600V]) × 2
9097 (Carrying case)
R6 (AA) × 1
Instruction Manual
