测定范围?1?71?1?77?1?71?1?77精确度交流电流(50/60Hz)20/200mA/2/20/200/500A±1

测定范围
?1?71?1?77?1?71?1?77
精确度
交流电流(50/60Hz)
20/200mA/2/20/200/500A ±1.5%rdg±5dgt(20/200mA/2A)
±2%rdg±5dgt(20/200A) ±2.5%rdg±5dgt(500A)
交流电流(WIDE)
20/200mA/2/20/200/500A

±1.0%rdg±3dgt(50/60Hz) ±5.0%rdg±5dgt(20/200mA/2A)(40~400AHz)

±1.5%rdg±3dgt(50/60Hz) ±5.0%rdg±5dgt(20/200A)(40~400Hz)

±2.0%rdg±3dgt（50/60Hz) ±5.0%rdg±5dgt(500A)(40~400Hz)



交流电压
600V ±2%rdg±5dgt(50/60Hz) ±5%rdg±5dgt(40Hz~400Hz)
电阻
200Ω ±1.5%rdg±5dgt
导体直径
Ø40mm
频率范围
40Hz~1kHz
输出电压
相对于各量程值的DC200mV(500A量程为500mV)
耐电压
3700V AC / 分钟
